▸ Model: LRS-75-24
▸ Brand: Mean Well (Original)
▸ Output: 24V DC / 3.2A (76.8W)
Mean Well LRS-75-24 | 75W 24V Switching Power Supply
| Specification | Detail |
|---|---|
| Model Number | LRS-75-24 |
| Output Power | 76.8W |
| Output Voltage | 24V DC (Adjustable: 22.8 ~ 26.4V) |
| Output Current | 3.2A |
| Input Voltage | 85 ~ 264 VAC |
| Frequency | 47 ~ 63 Hz |
| Efficiency | 90% (Typical) |
| Cooling Method | Free air convection (Fanless) |
| Dimensions (L×W×H) | 99 × 97 × 30 mm |
| Weight | 0.45 kg |
| Safety Standards | UL62368-1, TUV EN62368-1, EAC 62368-1 |
| EMC Standards | EN55032 (Class B), EN61000-3-2, -3 |
